2016 ASTEC GT104
Price:USD $189,945
Buy
2016 ASTEC GT104
Used and New
Description:
GT104 TRACK MOUNTED SCREEN
SCREEN
One (1) 2410 double deck screen: 4’ x 9’ screen with side tensioned top deck and end tensioned bottom deck
Screen driven by hydraulic variable speed vibrating mechanism mounted on screen; adjustable amplitude with add on weights; coil springs
Fines collecting hopper; Top and bottom deck discharge chutes; fixed 15 degree angle
Less screen cloth (top deck side tension; bottom deck end tension)
FRAME
Fabricated I-Beam style frame rails; Track mount design; Pendant remote control
HOPPER
5.25 cubic yard heaped capacity hopper
Hopper sides made of Hardox
BELT FEEDER
13’ x 42” (1050mm) belt feeder with hydraulic variable speed single motor drive; Formed plate; Impact Bed
Rubber lagged head pulley and self-cleaning wing pulley mounted on pillow block bearings; Screw type take-ups
Belting is Toughflex 630/2 9+3 with grade "X" cover; Vulcanized; Secondary style belt cleaner
UNDER SCREEN CONVEYOR
10' X 42” (1050mm) fixed conveyor with hydraulic drive; Adjustable back board
Rubber lagged head pulley and self-cleaning wing pulley mounted on pillow block bearings; Screw type take-ups; CEMA-C troughing idlers; CEMA-C return idlers; Return idler guards; Receiving hopper
Belting is EP400/3.4mm +2mm cover; Vulcanized; Primary belt cleaner
FINES SIDE CONVEYOR
One (1) 26' x 24” (650mm) fold out conveyor with hydraulic variable speed drive and rubber pulley; Folds for transport
Rubber lagged head pulley and self-cleaning wing pulley mounted on pillow block bearings; Screw type take-ups; CEMA-C troughing idlers; CEMA-C return idlers; Return idler guards; Receiving hopper
Belting is EP400/3.4mm + 2 mm cover; Vulcanized; Primary belt cleaner
BOTTOM DECK OVERS CONVEYOR
One (1) 26' x 24” (650mm) fold out conveyor with hydraulic variable speed drive and rubber pulley; folds for transport
Rubber lagged head pulley and self-cleaning wing pulley mounted on pillow block bearings; Screw type take-ups; CEMA-C troughing idlers; CEMA-C return idlers; Return idler guards; Receiving hopper
Belting is EP315/3.3mm + 1.5mm cover; Vulcanized; Chevron; Beater roller
OVERS CONVEYOR
9' x 42” (1050mm) conveyor with hydraulic variable speed drive; fixed discharge height; Impact Bed;
Rubber lagged head pulley and self-cleaning wing pulley mounted on pillow block bearings; Screw type take-ups; Impact bed in Loading area; CEMA-C impact troughing idlers; CEMA-C return idlers; Return idler guards; Receiving hopper
Belting is EP500/3.5mm + 2mm cover; Vulcanized; Chevron; Beater roller
POWER & HYDRAULICS
Kohler 74 HP Tier IV water cooled diesel engine; 55 gallon fuel tank; Oil Cooler; Engine mounted hydraulic pumps to operate all plant functions; 85 gallon hydraulic reservoir with return filters
NEMA-4 rated instrument panel; hour meter and emergency stop
SCREEN
One (1) 2410 double deck screen: 4’ x 9’ screen with side tensioned top deck and end tensioned bottom deck
Screen driven by hydraulic variable speed vibrating mechanism mounted on screen; adjustable amplitude with add on weights; coil springs
Fines collecting hopper; Top and bottom deck discharge chutes; fixed 15 degree angle
Less screen cloth (top deck side tension; bottom deck end tension)
FRAME
Fabricated I-Beam style frame rails; Track mount design; Pendant remote control
HOPPER
5.25 cubic yard heaped capacity hopper
Hopper sides made of Hardox
BELT FEEDER
13’ x 42” (1050mm) belt feeder with hydraulic variable speed single motor drive; Formed plate; Impact Bed
Rubber lagged head pulley and self-cleaning wing pulley mounted on pillow block bearings; Screw type take-ups
Belting is Toughflex 630/2 9+3 with grade "X" cover; Vulcanized; Secondary style belt cleaner
UNDER SCREEN CONVEYOR
10' X 42” (1050mm) fixed conveyor with hydraulic drive; Adjustable back board
Rubber lagged head pulley and self-cleaning wing pulley mounted on pillow block bearings; Screw type take-ups; CEMA-C troughing idlers; CEMA-C return idlers; Return idler guards; Receiving hopper
Belting is EP400/3.4mm +2mm cover; Vulcanized; Primary belt cleaner
FINES SIDE CONVEYOR
One (1) 26' x 24” (650mm) fold out conveyor with hydraulic variable speed drive and rubber pulley; Folds for transport
Rubber lagged head pulley and self-cleaning wing pulley mounted on pillow block bearings; Screw type take-ups; CEMA-C troughing idlers; CEMA-C return idlers; Return idler guards; Receiving hopper
Belting is EP400/3.4mm + 2 mm cover; Vulcanized; Primary belt cleaner
BOTTOM DECK OVERS CONVEYOR
One (1) 26' x 24” (650mm) fold out conveyor with hydraulic variable speed drive and rubber pulley; folds for transport
Rubber lagged head pulley and self-cleaning wing pulley mounted on pillow block bearings; Screw type take-ups; CEMA-C troughing idlers; CEMA-C return idlers; Return idler guards; Receiving hopper
Belting is EP315/3.3mm + 1.5mm cover; Vulcanized; Chevron; Beater roller
OVERS CONVEYOR
9' x 42” (1050mm) conveyor with hydraulic variable speed drive; fixed discharge height; Impact Bed;
Rubber lagged head pulley and self-cleaning wing pulley mounted on pillow block bearings; Screw type take-ups; Impact bed in Loading area; CEMA-C impact troughing idlers; CEMA-C return idlers; Return idler guards; Receiving hopper
Belting is EP500/3.5mm + 2mm cover; Vulcanized; Chevron; Beater roller
POWER & HYDRAULICS
Kohler 74 HP Tier IV water cooled diesel engine; 55 gallon fuel tank; Oil Cooler; Engine mounted hydraulic pumps to operate all plant functions; 85 gallon hydraulic reservoir with return filters
NEMA-4 rated instrument panel; hour meter and emergency stop
Information:
| Year | 2016 |
| Location | ELMA, New York |
| Stock Number | AG1240 |
| Hours | 3 |
| Serial Number | 164346 |
